EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1

產品型號: 100-GD-0700-V1

查看規格表
下載說明書

EVGA 100-GD-0700-V1  700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 1
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 2
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 3
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 4
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 5
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 6
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 7
  • EVGA 700 GD, 80+ GOLD 700W, 5 Year Warranty, Power Supply 100-GD-0700-V1 (100-GD-0700-V1) - Image 8

*照片上顯示的配件如有變更不另行通知。

Average Rating

 Review It



Promos

EVGA 700 Watts 電源供應器 產品型號 Efficiency ECO Mode Modular Warranty +12V Rail Rating Fan Size Japanese Capacitors Performance
EVGA SuperNOVA 750 G2, 80+ GOLD 750W, Fully Modular, EVGA ECO Mode, 10 Year Warranty, Includes FREE Power On Self Tester Power Supply 220-G2-0750-XR 220-G2-0750 Gold Yes Full 10 Year(s) 62.4A 140mm 100% Better

Cable Length

ATX Cable 1x 600mm
EPS Cable 1x 600mm
PCIE Cable 2x 550mm, 700mm
AC Power 1x 1500mm (m)
Modular Cable Type No

Connector Quantity

24 Pin ATX 1x
EPS (CPU) 1x8pin(4+4)
PCIE 4x8pin(6+2)
SATA 6x
Four-Pin Peripheral 3x
Floppy 1x

Power Specs

AC Input 110-240 VAC, 9.5-4.5A, 60/50 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 20A 20A 58.3A 2.5A 0.3A
699.6W
100W 699.6W 12.5W 3.6W
Total 700W

Additional Details

工作溫度範圍 0° to 40° C
Japanese Capacitors Main
ECO Mode No
MTBF 100,000 Hours
淨重 4 lbs
Size 86mm (H) x 150mm (W) x 140mm (L)
Approvals TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 3 2014 Requirement
風扇尺寸 / 軸承 120mm Sleeve Bearing

產品保固

This product comes with a 5 year limited warranty with registration.
EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.

80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads

5 Year Warranty and unparalleled EVGA Customer Support

Quiet and Intelligent Auto Fan for near-silent operation

Active Power Factor Correction

Heavy-duty protections, including OVP (Over Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)

Single 12V. Rail

DC-DC Converter improves 3.3V/5V stability
